Dredging Pump MTB3-BDA18

Dredging Pump MTB3-BDA18

3 Inches Dredging Pump Driven by Branco Engine BDA18

Versatility for small services

Dredge pump with movable (screwed) suction and discharge nozzles that makes and easier maintenance in case of dredging solids that may get stuck in the rotor.

Dredging Pump MTB3-BDA18
BRL 17.260,00*

*The informed value is refered to the price list defined for cash for individual sales, available for pick-up at our factory (no freight included). For special deals, multiple product quotes on the same order that includes shipping, different terms for payment, or exports, you must contact the sales department to receive the supplementary information.

Download our Complete Catalog
  • Operation Specifications
  • Technical description
  • Images

Especificações técnicas da Bomba Draga BM 694.000 com motor Branco BDA 18

Dados técnicos do modelo BM 694.000 / MTB3_BDA18
Model / Ref BM 694.000 / MTB3_BDA18
Maximum Flow 80 m³/h or 80.000 lts/h
Content Ratio 70% liquid / 30%solid
Max Suction Height 5 meters
Max Sucition Length 5 meters
Max Discharge Height 10 meters
Max Discharge Lenght 25 meters
Ø Suction Nozzle 3 inches
Ø Discharge Nozzle 3 inches
Weight 272 kg or 600 lb
Curva de vazão em metros cúbicos por hora conforme o comprimento da tubulação em metros, operando a 2200 RPM com motor de 15 CV. 3 inches Dredging Pump + Branco BDA 18 Engine RPM 2200 15 CV Engine BRAZMIX 100 90 80 70 60 50 40 0 25 50 75 100 Pipeline Length in meters m³/h
Curva de desempenho a 2200 RPM. Vazões aproximadas: 90 m³/h com 5 metros de tubulação; 85 m³/h com 15 metros; 80 m³/h com 25 metros; 75 m³/h com 35 metros; 65 m³/h com 50 metros; 55 m³/h com 75 metros; e 50 m³/h com 100 metros.
Dados da curva de desempenho
Comprimento da tubulação Vazão
5 meters 90 m³/h
15 meters 85 m³/h
25 meters 80 m³/h
35 meters 75 m³/h
50 meters 65 m³/h
75 meters 55 m³/h
100 meters 50 m³/h



Technical description

3-inches Diesel Driven Dredge Pump for suction of solid materials in conjunction with water (30% solids and 70% liquid).

Recommended for:

- Sand in rivers, lakes, and ponds
- Gravel and small stones in rivers, lakes, and ponds (maximum diameter of 2.5 cm)
- Mud, sludge, and well drilling residues
- Stormwater and river sewage
- Clean water (without suspended solids)
- Organic materials such as animal waste
- Flood irrigation

Not recommended for:

- Food products
- Potable water (intended for consumption)
- Organic materials with elongated fibers
- Corrosive liquids
- Concrete or similar materials
- Sprinkler irrigation or pressurized line irrigation

General Notes:

- This pump model is NOT self-priming.

- The assembly suffers abrasion wear when dredging solids, and it is impossible to say exactly how long it will last under these conditions.

- Pump manufactured from cast iron (casing, protective discs and sealing peripherals), nodular iron (bearing) and steel (rotor, shaft, bearings and screws).

- Approximate weight of the pack = 270 kg

- This pump has a rotation direction that is not compatible with the rotation direction of most tractor power take-offs (PTOs), however, it is still possible to use the pump to couple to the tractor if adaptations are made during coupling. Consult additional information for this purpose.

- It is recommended to use a foot valve on the suction hose to facilitate the priming process.

The priming process is when, before starting the engine, the entire suction hose and pump housing are filled with water, ensuring that it is full before starting the engine. This process allows the pump to generate negative pressure and continue suction on its own.

- During the dredging process, the suction hose must not suck in air. This will cause it to stop operating until a new priming process is performed.

IF YOU DO NOT HAVE EXPERIENCE WITH THE ASSEMBLING AND OPERATION OF MECHANICAL EQUIPMENT, CONSIDER THE POSSIBILITY OF ASSISTANCE FROM QUALIFIED PERSONNEL.

This is a mechanical device that requires the installation of an engine and coupling. Ensure your safety when operating the assembled equipment.

This pump is manufactured from cast material that is fragile to impacts, so it is necessary to handle it carefully during installation.

If you have any questions about the operating capabilities of the pump in your project, please contact our technical team through the available means.
